Polyimide Thermofoil Flexible Heaters With Thermistor

FOB Reference Price:Get Latest Price
US $1-100 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
ALI BROTHER
Model Number:
ALI-H-007
shape:
all kinds of shape
insulating strength:
UDC500V>=200M ohm
dielectrical strength:
UAC>=2000v
opeartion temperature:
<=232C
wattage density:
<=1.1W/cm2 or <=6.5W/cm2(with thermostat)
thickness:
<=0.2mm
weight:
<=278g/m2
Supply Ability
Supply Ability:
5000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
carton, wooden case and other suitable package
Port
Shenzhen
Lead Time :
7 days

Specifications

1. polyimide metal foil and metal wire
2.excellent insulation
3.strong dielectric strength
4.capability
5.lowest price

Due to its low thermal mass and superb electrical insulation, Kapton is ideal for applications that require a lightweight solution with fast and efficient thermal transfer.

Features:

Interior FEP binding stands 200°C.
Apply in vacuum environment.
Stand against most of chemical material such as acid, impregnant, alkali (except NaOH).
The size can be very small.
Thin and small curly semidiameter.

Temperature Range: -50°C~200°C, the max temperature is 200°C for the heater with paster.
Material: Kapton/FEP, polyimide membrane
Resistance Precision: ±10%ak±0.5Ω(taking max)
Medium Strength: 1000VRMS
Minimum Curve Semidiameter: (0.8mm)

Superior tensile strength and tear resistance

Resistant to radiation and most solvents

Transparency allows inspection of internal details

Ideal for extreme temperature environments

Multiple layers possible

We carry many other kapton heaters in different sizes and watts. Please ask if you don't see the size you need in our website.

We can made all heaters as you want to order and delivery within 7 days


Why Kapton

  • Better choice far high watt density heaters (those over 5 watts/in2). Also used for watt densities of 5 or less.
  • Excellent choice for heaters that require multi-zoned wattages or heaters that have many holes and/or cutouts.
  • May provide an economic advantage for high volume applications.

      • High tensile strength
      • Low outgassing
      • Excellent dimensional stability
      • Thin, lightweight profil
      • High watt densities
      • Transparent material


Insulation Characteristics

  • Transparent amber colored polyimide film
  • Top and bottom layer of Kapton® each with a thickness of .002″
  • Layers of adhesive (.001″)
  • .001″ element
  • Overall thickness of .007″

Kapton Heaters

Kapton FEP/Adhesive

Kapton/Acrylic Adhesive (Pyralux®)

Max size

12" x 24"

12"x30"

Thickness

0.007"-0.010"

0.007"-0.010"

Max temp

390°F

3000F

Max voltage

240 VAC

240VAC

Watt density

Up to 30 W/in²

Up to 30W/in2
